710-SWIR Hyperspectral Camera

Easy to Use, Affordable, SWIR Hyperspectral Imaging System

SOC710-SWIR covers the near-infrared 900-1700 nm spectral range.

Completely self-contained turnkey system. No external scanning stages needed.

Plug-and-play operation with standard microscope camera ports.

Open source ENVI-compatible data format.

Preview camera provides live video for rapid focus adjustments.

Automated data acquisition enables hands-off time-lapse experiments.

Parameter	Specification
Spectral Range (nm)	900 – 1700
Spectral Channels	288
Spectral Bandwidth (nm)	2.78
Spectral Resolution (FWHM) (nm)
Spatial Pixels	512
Aperture	f/2.0
Pixel Size (µm)	15
Noise Equivalent Spectral Radiance (NESR) (W/m²-sr-nm)	1.258E-03 @ 550nm*
Bit Depth	12
Stray Light	< 0.5%
Objective Lens	C-Mount / SWIR corrected
Max Frame Rate (fps)	107
Interface	USB 2.0
Weight (kg / lbs)	5.44 / 12.0
Dimensions (cm)	13 x 20.3 x 27
Power (V)	12 DC / 100-240 AC
Export Control	ECCN #6A003

Item	Description
SOC710 Rechargeable Battery	20000mAh Portable Battery. Input: 15-19V/1.3A Output:12V/4A.
Ruggedized Tablet Computer	Ruggedized tablet computer with glare resistant screen, GPS, snap shot capability and SOC data acquisition software.
Calibration Panel (NIST)	NIST Traceable Spectral Reflectance Calibration Panel (nominal 18% reflectance in VNIR). Includes NIST Traceability Certificate of Analysis.
SOC710-SWIR 1-Year Extended Warranty	12-month Extended Warranty. Extends the standard 12-month warranty to 24 months. Must be purchased with the respective instrument at the time of sale.

Focal Length (mm)	Field Of View (deg)
12.5	34.2
25	17.5
